Radio transmission system
The radio transmission system is a functionally safe system for wireless signal transmission of switching impulses of safety edges on doors and gates. Due to its high compatibility with all common motor control systems, our system is universally applicable. It can be retrofitted easily. The radio transmission system replaces cable-linked or transponder systems.
Industries
Advantages
-
wireless signal transmission -
space-saving -
weatherproof -
compatible with all common motor control systems -
long range
Your benefits
Transmitter
- Multi-frequency system – four self-setting channels
- One transmitter for up to two safety edges
- 50 metres usable range, 100 metres nominal range (open field)
- Operating temperature -20°C to +55°C
- Protection class IP65
Receiver
- Capacity for six transmitters
- Transmission power 25 mW
- Operating temperature -20°C to +55°C
- 50 metres usable range, 100 metres nominal range (open field)
- Protection class IP65 (with cable screw connection)
Applications
Protection for main and secondary closing edges on gate systems:
- Sliding gates
- Quick-folding gates
- High-speed gates
- Sectional gates
- Roller gates
Downloads
-
Doors, gates and windows brochure (2.96 MB) -
Certificate 44 207 13749706 RB3 system (74.88 KB)
